Genset Control System

Genset Control System

Jiolat Auto Gas Genset Control System is Processional Designed Based On Jiolat 15 Years' Experience

On Gas Engine Field, Epitomized Most Gas Genset Advantage, Features Are As Follows.
  1. High Integration (freescale Dual-core Processor. Wideband Oxygen Sensor High - Energy Sequence Innition. EOBD)
  2. Powerful, Scalable (suports A Variety of Control Strategies : Can Bus. Supports Multi-ECU)
  3. Stability Speed Regulation
  4. Low Gas Consumption Rate (using Lean - Burn Technology, Theentire Process Can Be Controlled At The Optimum Air-fuel Ratio, Combustion Stability And Sufficient)
  5. Low Echaust Temperature. Life Time.
  6. Can Match Too Many Gas Supply Systems Based On Different Gas Source.
  7. Support Different lgnition Solution. (sequence lanition sequence : Grouping lanition)
  8. Close Loop Control. rich L/o Output. Multiply Communication Protocols. Real Time Diagnosis
Jiolat Auto Gas Concentrates On The Manufacturing Providing And Service For Diesel Generator Set. gas Generator set.gas Generator Set Gas Concentration For Many Years. We Have Deliverd More Than 1 Thousand Generator Sets To Customers Over The World.

MODEL PC4B24G PC4B30G PC4B45G PC6B68G PC6B100G PC6C133G PC6L176G PCN266G PCK440G PCK810G PCK1000G
PRIME POWER 20 26 40 60 85 113 160 226 374 688 850
STANDBY POWER 24 30 44 68 97 133 175 263 430 810 1000
BRAND PROW-BEST PRO-BEST PRO-BEST PRO-BEST PRO-BEST PRO-BEST PRO-BEST PRO-BEST PRO-BEST PRO-BEST PRO-BEST
GENSET STEADY RATE <1% <1% <1% <1% <1% <1% <1% <1% <1% <1% <1%
ENGINE MODEL 4B3.9 4BT3.9 4BTaa3.9 6BT5.9 6BTaa5.9 6CTaa8.3 6LTaa8.9 NTaa855 KTaa19 KTaa38 Ktaa50
PRIME POWER 24 30 45 68 100 133 176 266 440 810 1000
INTAKE MODE NATURAL ASPIRATION TURBO - CHARGED TURBO CHARGED AND AIR COOLED turbo charged and air cooled turbo charged and air cooled turbo charged and air cooled turbo charged and air cooled turbo charged and air cooled turbo charged and air cooled turbo charged and air cooled turbo charged and air cooled
OF CYLINDERS 4 4 4 4 6 6 6 6 6 12 16
RATED SPEED 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500
BORE 102 102 102 102 102 114 114 140 159 159 159
STROKE 120 120 120 120 120 135 145 152 159 159 159
COMPRESSION RATIO 10.5:1 10.5:2 10.5:3 10.5:4 10.5:5 10.5:6 10.5:7 10.5:8 10.5:9 10.5:10 10.5:11
DISPLACEMENT 3.9 3.9 3.9 5.9 5.9
SPEED GOVERNING ELECTRICAL ELECTRICAL ELECTRICAL ELECTRICAL ELECTRICAL ELECTRICAL ELECTRICAL ELECTRICAL ELECTRICAL ELECTRICAL ELECTRICAL
STARTING METHOD 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START 24v ELECTRIC START
LUBE SPECIFICATION 15wcl_40 15wcl_41 15wcl_42 15wcl_43 15wcl_44 15wcl_45 15wcl_46 15wcl_47 15wcl_48 15wcl_49 15wcl_50
LUBE CAPACITY 11 11 11 11 16.3 16.3 16.3 38.6 50 135 204
BRAND 9OPTIONAL STAMFORD STAMFORD STAMFORD STAMFORD STAMFORD STAMFORD STAMFORD STAMFORD STAMFORD STAMFORD STAMFORD
MODEL NUMBER P1144E
VOLTAGE 380-415 380-415 380-415 380-415 380-415 380-415 380-415 380-415 380-415 380-415 380-415
POWER 20 32 40 96 96 112 145 280 400 728 1000
SPEED 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500
PHASE 3 3 3 3 3 3 3 3 3 3 3
POWER FACTOR 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
STEADY VOLTAGE REGULATION ±1.5% ±1.5% ±1.5% ±1.5% ±1.5% ±1.5% ±1.5% ±1.5% ±1.5% ±1.5% ±1.5%
